Metal Stud And Track Roll Forming Machine For Ceiling Profile CE Certified
Metal Stud And Track Roll Forming Machine For Ceiling Profile CE Certified Metal Stud And Track Roll Forming Machine For Ceiling Profile CE Certified Metal Stud And Track Roll Forming Machine For Ceiling Profile CE Certified

Metal Stud And Track Roll Forming Machine For Ceiling Profile CE Certified

Product Details:
Place of Origin: CHINA
Brand Name: NKH MACHINERY
Certification: CE/SONCAP/CSA
Model Number: YX110
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: negotiation
Packaging Details: NUDE CARGOES FOR ROLL FORMER WITH CUTTER IN 20/40FT CONTAINER, WOODEN BOX FOR PLC CONTROL CABINET
Delivery Time: 40 WORKING DAYS
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10 UNITS/MONTH
Contact Now

Detail Information
Name: Metal Stud Roll Forming Machine Raw Material: PPGI Sheets, G245-G550
Shaft Material: 45#, High Precision Control System: PLC Control System
Cutting Blade Material: Cr12, Heat Treatment Roller Material: 45# Steel, CNC Lathes, Hard Chrome Coated
Highlight:

ceiling roll forming machine

,

furring channel roll forming machine

Product Description

Roll forming machine for ceiling profile, metal stud furring channel



Quick Detail:

  1. Thickness : 0.4-0.6mm
  2. Material : G350 PPGI
  3. Input width : 156mm
    1. Effective width: 101mm
    2. Material weight : 1.5Tons
    3. Coil inner diameter : 508mm
    4. Driven way: by driven motor
    5. Cutting way: after cut-off, there is waste
    6. Cutting tolerance : ±1mm

Application:

This production line has been designed to produce metal wall or sandwich panels with PU or Polyurethane insulated and various decoration patterns embossed, engraved or printed on the metal face.



Machine list:

  1. 1.5T*300mm manual un-coiler
  2. Roll former
  3. Hydraulic cutting device
  4. Run out table
  5. PLC control system

Description/Technical Parameter details of complete line:

  • 1.5TX300mm Manual Un-Coiler

Un-powered; Load capacity= MAX.1.5Ton

Coil inner–diameter=410-570mm

Coil Width= MAX.300mm

  • Roll forming machine with cutting details as below table :
Suitable roll forming material Color steel sheet or galvanized steel sheet
Thickness 0.4mm-0.6mm
Coil input width 151mm
Carriage Frame design Wall-plate-frame-design
Rolling mills forming stages

12+4 stages

Including 4 stages of embossing rollers
Material of forming roller 45# steel, CNC lathes, Hard Chrome Coated
Shafts Diameter Φ60mm
Main motor power 4Kw with reducer
Rolling speed of roll former 15m/min
Hydraulic group power 3.0 Kw
Material of cutting blade Cr12, hear treatment
Electric Voltage Standard 380V/50Hz/3PH or as the customer's requirements
Major Color of Machine Painted RAL 5015(Blue) or as per customer’s requirements
  • PLC Control System

Siemens brand PLC and touch screen, Schneider/ Shihlin/ Delta brand Inverter, Omron encoder

Cut-to-length tolerance≤±1mm

Control Voltage 24V

  • Product Rack Un-powered, 3 units

Profile Drawing/Layout/Equipment reference pictures:

Metal Stud And Track Roll Forming Machine For Ceiling Profile CE Certified 0Metal Stud And Track Roll Forming Machine For Ceiling Profile CE Certified 1

Tag:

ceiling roll forming machine

furring channel roll forming machine

light keel roll forming machine
