845 Roof Tile Panel Roll Forming Machine Tile Roof
845 Roof Tile Panel Roll Forming Machine Tile Roof
845 Roof Tile Panel Roll Forming Machine Tile Roof 845 Roof Tile Panel Roll Forming Machine Tile Roof 845 Roof Tile Panel Roll Forming Machine Tile Roof 845 Roof Tile Panel Roll Forming Machine Tile Roof 845 Roof Tile Panel Roll Forming Machine Tile Roof

845 Roof Tile Panel Roll Forming Machine Tile Roof

Product Details:
Place of Origin: CHINA
Brand Name: NKH MACHINERY
Certification: CE
Model Number: YX845
Payment & Shipping Terms:
Minimum Order Quantity: 01 set
Price: negotication
Packaging Details: nude cargoes
Delivery Time: 60 working days
Payment Terms: T/T, , L/C
Supply Ability: 02 sets/month
Contact Now

Detail Information
Name: Metal Tile Roofing Machine Weight: 5T Or As Request
Raw Material: Pre-Painted Sheets Shaft Material: 45#, High Precision
Control System: PLC Control System Roller Material: 45# Steel, CNC Lathes, Hard Chrome Coated
Cutting Blade Material: Cr12, Heat Treatment Usage: Steel Construction

Product Description

845 Roof Tile Panel Roll Forming Machine Tile Roof 0

845 Tile Roof Panel Roll Forming Machine



Technical Parameters:


No. Item Specification
1 Material PPGI,GI,AI
2 Equipment operation Automatic
3 Voltage 380V 50Hz 3Phase or as your requirement
4 Thickness of sheet (mm) 0.3-0.7mm
5 Material width(mm) As your requirement
6 Cover Width of the sheet after formed as your drawing
7 The size of the roll forming machine 12000mmx1600mmx1400mm
8 Speed 4-6m/min
9 Diameter of shaft 75mm
10 Weight of the Machine 12000KGS
11 Material of rollers 45 steel quenched and chromed
12 Motor brand Siemens
13 PLC Siemens or Delta or Mitsubushi


 845 Roof Tile Panel Roll Forming Machine Tile Roof 1
